Y Splitter 16 Amp 3 Pin 2 Way | 110V IP44

Y Splitter 16 Amp 3 Pin 2 Way | 110V IP44
PLUG DETAIL - 16AMP 110V PLUG TO 2 X 16AMP 230V SOCKETS MOULDED HEAVY DUTY Y SPLITTER
MOULDED DETAIL 16AMP 110V PLUG TO 2 X 16AMP 230V SOCKETS MOULDED HEAVY DUTY Y SPLITTER
SOCKET DETAIL- 16AMP 110V PLUG TO 2 X 16AMP 230V SOCKETS MOULDED HEAVY DUTY Y SPLITTER
3 CORE 2.5MM H07RN-F RUBBER CABLE
Y Splitter 16 Amp 3 Pin 2 Way | 110V IP44
PLUG DETAIL - 16AMP 110V PLUG TO 2 X 16AMP 230V SOCKETS MOULDED HEAVY DUTY Y SPLITTER
MOULDED DETAIL 16AMP 110V PLUG TO 2 X 16AMP 230V SOCKETS MOULDED HEAVY DUTY Y SPLITTER
SOCKET DETAIL- 16AMP 110V PLUG TO 2 X 16AMP 230V SOCKETS MOULDED HEAVY DUTY Y SPLITTER
3 CORE 2.5MM H07RN-F RUBBER CABLE

Y Splitter 16 Amp 3 Pin 2 Way | 110V IP44

  • 1 metre heavy duty moulded two way splitter. Each leg is approx 50cm.
  • 16Amp 3Pin Yellow 110V Commando/Ceeform connectors.
  • Nexans Titanex 3Core 2.5mm² HO7RN-F tough and flexible cable.
  • Single 80mm clear heatshrink for your ID label.
  • For full specification see tabbed area below.
£0.00
£38.50
£0.00
£38.50
Earn 0 reward points

In stock: 2

Sorry! We're out of stock

The details

  • Applications

    For use in industrial, event, catering, commercial and temporary power distribution applications

  • Product Specification

    Specification:

    • Cable: 2.5mm² 3 Core H07RN-F Rubber
    • Plug: 16Amp 230V 3 Pin 2P+E IP44 Yellow Plug PCE 013-4
    • Socket: 2 x 16Amp 230V 3 Pin 2P+E IP44 Yellow Socket PCE 213-4
    • Terminations: Ferruled
    • Heatshrink: 1 x 80mm Clear
    • Voltage: 110V
    • IP Rating: IP44
    • Max Current: 16A
    • Test: Portable Appliance Test (PAT)
    • Standard: BS7909
    • Code: SH116M2
